Description
SPECIFICATIONS
After-sale Service: Online technical support
Application: Villa
Brand Name: NoEnName_Null,YG
Certification: CE
Color: Customized Colors
Design Style: Contemporary
Hign-concerned Chemical: None
Material: Sandwich Panel, Steel, Wooden,Log
Origin: Mainland China
Place of Origin: Henan, China
Product Type: Expandable Container
Use: Villa
Warranty: 3 years
Specification
1.This is a custom machine. The price on the page is only a deposit, and does not include shipping, accessories and packaging fees.
2.Please contact Alger for a free quote❤
Whatsapp/WeChat/Phone number : +86 13633712108
Email : salesmachinery@yg797.com
|
item |
value |
|
Warranty |
3 years |
|
After-sale Service |
Online technical support |
|
Application |
Courtyard |
|
Place of Origin |
China |
|
|
henan |
|
Brand Name |
YG |
|
Material |
Sandwich Panel |
|
Use |
House |
|
Product Type |
Container Houses |
|
Design Style |
Contemporary |
|
|
|
|
40ft Expandable House Specifications |
|
|
||
|
Dimensions |
External dimensions (mm) |
W6400*L11600*H2480(lower side 2270) |
||
|
|
Internal dimensions (mm) |
W6280*L11200*H2280(lower side 2150) |
||
|
|
Folding (mm) |
W2160*L11600*H2480 |
||
|
|
Total weight(kg) |
4800千克 |
||
|
Structure |
Top side beam |
t2.5mmQ235B |
||
|
|
Bottom side member |
t2.5mmQ235B |
||
|
|
End side beam |
t2.5mmQ235B |
||
|
|
Side wall frame |
t2.5mmQ235B |
||
|
|
Subframe |
t2.5mmQ235B |
||
|
|
Hanger |
t4mmQ235B |
||
|
|
Folding hinge |
13mm Galvanized hinge |
||
|
|
Overall framework protective coating |
Electrostatic spraying/straight white plastic powder |
||
|
|
The top and bottom of the middle cabinet |
80*100*2.5 thick tube |
||
|
|
The top and bottom of the side cabinet |
40*60*1.7 thick tube |
||
|
Top |
External roof |
0.5mm galvanized sheet |
||
|
|
Indoor ceiling |
t0.3mm 831ceiling board |
||
|
Board |
Roof insulation layer |
t50mm EPS composite board |
||
|
|
Side front and rear wall panels |
t75mm EPS composite board |
||
|
|
Internal partition |
t50mm EPS composite board |
||
|
Floor |
Middle floor |
glass magnesium board or cement fiber board |
||
|
|
Side floor |
Bamboo flooring |
||
|
Electric |
Electrical wiring must be installed strictly in accordance with moisture-proof regulations, and all electrical products must comply with CE certification. Connect the circuit according to the electrical engineering specifications. Indoor: 3 LED lights, 3 five hole single opening sockets, 3 ten hole sockets, 3 air conditioning sockets, and 1 20A leakage protector. |
|
||
|
|
Voltage 220V, 50Hz |
|
||
|
Door |
Aluminum alloy glass door |
|
||
|
Window |
Aluminum windows |
|
||
|
Warranty |
One year warranty |
|
||
Company Profile
1,A:Do you provide on-site installation services? B:We provide very detailed installation guidance drawings and videos for each project. For large-scale projects, we will have installation workers and supervisors on site. The cost of on-site service should be negotiated with the customer.
2,A:What is your delivery time? B:Normally, the delivery time is 15 days after receiving the deposit. For large orders, delivery time should be negotiated.
3,A:How to control the quality of one's own products? B. Design quality: Anticipate potential issues and provide high-quality design solutions. b. Raw material quality: selecting qualified raw materials c. Production quality: precise manufacturing process, experienced workers, and strict quality inspection
4,A:What designs do you have in different climates (how do products adapt to different climates)? B:High wind area: Improve the wind resistance of the internal structure. Cold zone: Increase the thickness of the wall or use good insulation materials to improve the compressive strength of the structure. High corrosion areas: Use corrosion-resistant materials or paint anti-corrosion coatings.
